Android voice control in smart house with the help of Raspberry Pi

Jovan Krstić, Secondary school of electrical engineering “Nikola Tesla”,
Niš, Aleksandra Medvedeva, 18, tel.+38162/8093100, E-mail:jovan-97@hotmail.com

Introduction

The inprovement of information and communication
technologies involves their wide usage in remote device
control. Automation system developed in the paper is based
on the use of android application for users’communication
with the web server located in the controlled object. The
server is installed on Raspberry Pi computer, which
contributes to significant reduction of device dimensions.
The control can be performed by using voice commands
from any device that supports download and installation of
Android applications. It involves lighting control,
household appliances control, temperature and humidity Picture 2. The android application's screen shot
control, as well as object surveillance.
The automation of object control is based on web server. It
consists of Raspberry Pi software and application control
The system's structure software created in Pyton programme language. If any of
the sensors is activated, microcontroller generates
The system consists of Android application and web server interruption, activates the alarm and informs the user about
installed on Rasperry Pi computer. Sensors and relays are the situation by sending an e-mail. The user can switch the
directly connected with the main controller. The object can alarm directly from the application. The massage generated
be controlled and monitored from a distant location by on a web page is shown in picture 3.
using Android application, which communicates with the
web server via the Internet. The internet access can be
achieved via Wifi or 3G/4G nerwork. Hardware structure of
the system is shown with the block scheme in the picture 1.

Picture 3. The web page with generated massage

Conclusion

The smart house control system is completely developed
and tested in order to show its efficiency. There is a
possibility of its upgrading and further development by
Pisture 1. System’s structure
involving many different functions in the software, as well
as installing wireless network connection.
The system's hardware base consists of Raspberry Pi
computer including drivers(relays) for devices’ switching Literature
on, lighting controll, alarm, door and windows sensors,
smoke sensor, temperature and humiditi sensor SHT 75 [2]. [1] J. Krstić, D. Stajić; Web Home Controller, The Second
Raspberry Pi performs all the necessary functions, similar Olimpisc in technical creativity of young people in
to desktop computer, however lowvoltage periferials enable Southeasetern Europe, Zrenjanin, 28. Avgust 2014.
easy connection with I/O devices. The systems’ software is
developed on Android operation systems platforms witch is [2] Sensor S. Prasad , P. Mahalakshmi, A. John Clement
used by most mobile devices and this created in B4A Sunder ,R.Swathi; Smart Surveillance Monitoring System
programme language. The user's command can also be Using Raspberry PI and PIR.
performed via Google speech recognition. The android [3] Raspberry Pi: http://www.raspberrypi.org/
application's screen shot during connection is showed in [4]http://www.sensirion.com/fileadmin/user_upload/custom
picture 2.
ers/sensirion/Dokumente/Humidity/Sensirion_Humidity_S
HT7x_Datasheet_V5.pdf
